B field at the centre of a current-carrying semi-circular loop


  • Please log in to reply
8 replies to this topic

#1 Sriman Dutta

Sriman Dutta

    Molecule

  • Senior Members
  • 474 posts
  • LocationKolkata, India

Posted 23 December 2016 - 06:01 AM

Hello everyone,

As shown in the diagram, there is a semi-circular loop of current carrying wire, such that point P is the centre of the semi-circle and r is the radius. What shall be the magnetic flux density at the centre P?

I presume that the diagram must be treated by the Ampere's Law. So,

 B=\frac{\mu_0 I}{2\pi r}

Attached Thumbnails

  • WP_20161223_11_25_29_Pro.jpg

Edited by Sriman Dutta, 23 December 2016 - 06:02 AM.

  • 0
We are what we repeatedly do.
Excellence is then not an act but a habit.
-Aristotle

#2 Bender

Bender

    Molecule

  • Senior Members
  • 419 posts

Posted 23 December 2016 - 01:33 PM

Half a loop, so half the flux density of a full loop.


  • 0

#3 Sriman Dutta

Sriman Dutta

    Molecule

  • Senior Members
  • 474 posts
  • LocationKolkata, India

Posted 23 December 2016 - 03:19 PM

So, the denominator should be 4\pi r


  • 0
We are what we repeatedly do.
Excellence is then not an act but a habit.
-Aristotle

#4 Bender

Bender

    Molecule

  • Senior Members
  • 419 posts

Posted 23 December 2016 - 09:44 PM

On my phone, right now, but I think the pi is canceled out.
  • 0

#5 Sriman Dutta

Sriman Dutta

    Molecule

  • Senior Members
  • 474 posts
  • LocationKolkata, India

Posted 24 December 2016 - 05:18 AM

On my phone, right now, but I think the pi is canceled out.

Why and how ?


  • 0
We are what we repeatedly do.
Excellence is then not an act but a habit.
-Aristotle

#6 Bender

Bender

    Molecule

  • Senior Members
  • 419 posts

Posted 24 December 2016 - 08:15 AM

Why and how ?

Because you integrate over half a circle, which in this case comes down to a multiplication with \pi R



Derivation for full loop


  • 0

#7 Sriman Dutta

Sriman Dutta

    Molecule

  • Senior Members
  • 474 posts
  • LocationKolkata, India

Posted 24 December 2016 - 09:29 AM

Thanks Bender......... :-)



Here I summarize all the formulae for four different situations.



For a straight wire carrying current

 B=\frac{\mu_0 \mu_r I}{2 \pi r}

For a single loop of wire

 B=\frac{\mu_0 \mu_r I}{2r}

For a solenoid of length l and having n turns

 B=\frac{\mu_0 \mu_r nI}{l}

For a toroid of single turn and of radius r

 B=\frac{\mu_0 \mu_r nI}{2 \pi r}



Are they correct??


  • 0
We are what we repeatedly do.
Excellence is then not an act but a habit.
-Aristotle

#8 Bender

Bender

    Molecule

  • Senior Members
  • 419 posts

Posted 25 December 2016 - 11:12 PM

Yes. I double checked with the hand book I use (Giancoli )
  • 0

#9 Sriman Dutta

Sriman Dutta

    Molecule

  • Senior Members
  • 474 posts
  • LocationKolkata, India

Posted 26 December 2016 - 06:10 AM

Thanks.
